same day repair Fix your radio yourself - this weekend

RBZ Hard Drive or SSD . . its easier to replace you RBZ Hard Drive
than to replace you RBZ System.

Russell in Kansas said  "Installation was a breeze, problems were
fixed and  you saved me more than a $1000 !  I am a huge fan."

read There are 2 versions of RBZ systems.  Early systems have model numbers with the numbers 4678 or 4959 near the right end.  There is a sticker on the top of your system's case with the model number.

A quick way to determine your RBZ version:   In "System Information" if your Application Version is 10.00.11 or less, you have the "Early" RBZ system. (Version 10.00.11 is the final version for the first RBZ model.)  If your Application Version is 20.xx.xx or greater, you have the "Later" RBZ model.

Why No Disk-Image ?     RBZ hard drives have a Security lock applied in their Firmware and cannot be restored with a Disk-Image.

Hard Drive Recovery for MyGig Radio, music, U-Connect and Navigation

MyGig Problem ?    Very likely file corruption or a failing hard drive

Hard Drive Recovery for MyGig Radio, music, U-Connect and Navigation

MyGig RBZ Hard Drive or SSD Drive - a 1 hour Do-It-Yourself solution

Replacement MyGig RER Hard Drive

If your MyGig hard drive has failed or the data is corrupt, a pre-loaded MyGig RBZ replacement hard drive is the easiest repair available in a new Standard Duty Hard Drive  or an SSD drive.

Cold Climate ?   A Standard Duty drive will not spin up below 10°F.
An SSD is recommended for very cold climates.

MyGig RER Tools  Optional  high quality Pro-Fit Dash Pry-Tool

Use PayPal

With or Without a PayPal account

ITEMS BELOW: 40GB and 60GB Drives for Moderate Climates - Read about using a Standard Duty drive.

 ALERT  Just like your current RBZ drive, all drives below are locked and cannot be copied or re-imaged.

40GB MyGig RBH Disk-Image 40GB MyGig RBZ Hard Drive - new Standard Duty Hard Drive
  • For 2011 and later MyGig RBZ Models.
  • MyGig OEM configuration on a new 40GB standard duty hard drive.
  • Will not Spin-Up below 10°F.  See drives for cold climates below.
  • OPTIONAL High quality Pro-Fit dash pry-tool

See the TEST DRIVE return policy and WARRANTY below


ITEMS BELOW: Solid State (SSD) and Hard Drives for Cold Climates   (below 10°Fahrenheit)


40GB MyGig RBH Disk-Image 64GB MyGig RBZ SSD - new 64GB Solid State Drive  (SSD)
  • For 2011 and later MyGig RBZ Models.
  • MyGig OEM setup configured on a new 64GB SSD drive (Kingspec or Transcend)
  • Provides 46 GB music space compared to 28GB with your current drive
  • This drive is recommended for cold climates.  Field tested in Canada for the last 2 years.
  • OPTIONAL High quality Pro-Fit dash pry-tool

See the TEST DRIVE return policy and WARRANTY below


40GB MyGig RER Disk-Image 40GB MyGig RBZ Hard Drive - new Automotive Duty Hard Drive
  • MyGig OEM configuration on a new 40GB automotive duty hard drive.
  • The same Automotive Grade hard drive models in Porsche, Mercedes and MyGig units
  • Designed for cold climates | rated down to - 22F (-30C).
  • OPTIONAL High quality Pro-Fit dash pry-tool

See the TEST DRIVE return policy and WARRANTY below

40GB MyGig RER Disk-Image 40GB NEW RBZ Installation on a Slightly Used Automotive Duty Hard Drive

Used Drives ?  One of Chrysler's navigation manufacturbzs recalled thousands of systems with faulty main-boards. We bought several of the hard drives when these systems were returned and liquidated by the manufacturbz. They have been tested, wiped clean and re-configured as RBZ drives.

This drive is identical to the drive above except the new RBZ configuration has been applied to a low-hour
used drive.  The same original equipment Automotive Grade  drive with the same 1 year warranty

  • Designed for cold climates | rated down to - 22F (-30C).
  • Guaranteed to have less than 400 "Power On" hours - used less than 12% of typical service life.
        Below: Event Log on one of our low-hour used drives with a new RBZ installation:
  • Power on Time
  • OPTIONAL High quality Pro-Fit dash pry-tool

See the TEST DRIVE return policy and WARRANTY below

Add Pry Tool ?

$98

plus Priority Mail

$7.00 USA

$24.95 Canada


Add Pry Tool ?

$148

plus Priority Mail

$7.00 USA

$24.95 Canada

Add Pry Tool ?

$138

plus Priority Mail

$7.00 USA

$24.95 Canada



Slightly Used Hard Drive
New RBZ Installaiton
1 Year Warranty

Add Pry Tool ?

$118

plus Priority Mail

$7.00 USA

$24.95 Canada

MyGig RBZ problems caused by a bad hard drive

 ALERT  If your system is rebooting or freezing or crashing, check this System-Test before ordering a new MyGig Hard Drive.

Before your order a Hard Drive or a Solid State Drive (SSD): Check the list of hard drive related problems below to determine if your MyGig problem is caused by the hard drive.

(AM-FM-Sirius radio problems are not on this list because radio features do not depend on the hard drive)

Print this list to test in your vehicle

1. No Disk space in Manage HDD menu

2. HDD Music or Pictures aren't listed

3. HDD Music is listed but won't play

4. Can't upload Music from USB or CD

5. Gracenote Version not shown in System Information menu

6. Vehicle Splash Screen hangs for 15-30 seconds on startup

7. Diagnostic tests are not available

If you have one or more of these problems, DO NOT attempt to install a Software Update. If the Update sequence crashes when it tries to write data on the hard drive, it often causes permanent corruption in your firmware. This may leave your system in an endless reboot or with other problems that require a major repair or the replacement of your RBZ system.

! ! ALERT ! !  Before You Order . . . If your system CONSTANTLY RESTARTS, run THIS TEST to see if its caused by your hard drive.

Test Drive

If testing shows a new hard drive can't fix the problem with your system, you can
return the drive and tools within 30 days for a refund minus a $38 USD return fee.
Buyer pays for return shipping with a method that provides tracking.

Warranty

  • 1 Year Exchange for a defective Automotive Duty hard drive.
  • 90 Day Exchange for a defective Standard Duty hard drive.
    [Standard Duty drives include new drives made by Toshiba, Samsung and Fujitsu]

  • 1 Year Exchange for a defective Solid State Drive.
  • Your MyGig system cannot be damaged by renewing your hard drive configuration with a Disk-Image or a replacement MyGig hard drive. Nothing on the hard drive is written to your system's firmware.
  • Occasionally MyGig Software Updates and Gracenote Updates create issues with the system firmware. As a no-charge courtesy, MYGIG-DISK.COM provides Downloads of Software updates released by FCA US LLC. We are not responsible for problems that may arise from the installation or the failed installation of MyGig Software updates.

Licensing Compliance

MyGig-Disk.com is not affiliated with FCA US LLC.  "MyGig" and "Uconnect" are registered trademarks of FCA US LLC.

The MyGig replacement hard drive or Disk-Image are each system recovery media to restore a licensed MyGig system to its
working condition.  The MyGig Operating System and MyGig Applications reside in the MyGig system and are not distributed
on hard drives or disk images offered on this site.
